Mainly used in electric doors and windows, lifting equipment,gateways, barrier,elevators,industrial control, security industries and other fields.
1. Support Tuya APP network connection
2. Support 433.92mhz radio frequency communication
3. Input voltage AC/DC9-24V
Working voltage: AC:9-24V, DC:12-24V
Contact current: <20A@24V DC
Wlan Standard: IEEE802.11b/g/n
Working Frequency: 2.4G ～2.5G(2400M ～2483.5M)Hz/433Mhz
Encryption type: WEP/TKIP/AES
Security regime: WPA/WPA2
Receiving Sensitivity:802.11 b: -91 dbm (11 Mbps) 802.11 g: -75 dbm (54 Mbps) 433 :-112 dbm
Static current: <100mA
Working environment: -40℃～ +80℃,20% ～ 93%
Storage environment: -20℃～ +70℃,20% ～ 93%
Remote Control Capacity: <30
Outputs mode: Momentary\inter-locking\self-latching(Momentary mode working in a settable timing control)
Decoder type: 1527/2262
Product dimension: 94*60*28.5mm
